AOD4189
Or copy the link below:
- Mfr.Part #
- AOD4189
- Manufacturer
- Alpha and Omega Semiconductor, Inc.
- Package / Case
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Datasheet
- Download
- Description
- MOSFET P-CH 40V 40A TO252
- Stock
- 49,477
- In Stock ：
- 49,477
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Alpha and Omega Semiconductor, Inc.
- Product Category :
- Transistors - FETs, MOSFETs - Single
- Product Status :
- Active
- Input Capacitance (Ciss) (Max) @ Vds :
- 1870 pF @ 20 V
- Drive Voltage (Max Rds On, Min Rds On) :
- 4.5V, 10V
- Rds On (Max) @ Id, Vgs :
- 22mOhm @ 12A, 10V
- Technology :
- MOSFET (Metal Oxide)
- Current - Continuous Drain (Id) @ 25°C :
- 40A (Tc)
- Power Dissipation (Max) :
- 2.5W (Ta), 62.5W (Tc)
- Gate Charge (Qg) (Max) @ Vgs :
- 41 nC @ 10 V
- FET Feature :
- -
- Package / Case :
- TO-252-3, DPak (2 Leads + Tab), SC-63
- Mounting Type :
- Surface Mount
- Operating Temperature :
- -55°C ~ 175°C (TJ)
- Vgs(th) (Max) @ Id :
- 3V @ 250µA
- Supplier Device Package :
- TO-252 (DPAK)
- Vgs (Max) :
- ±20V
- FET Type :
- P-Channel
- Drain to Source Voltage (Vdss) :
- 40 V
- Datasheets
- AOD4189
P-Channel Tape & Reel (TR) 22m Ω @ 12A, 10V ±20V 1870pF @ 20V 41nC @ 10V 40V TO-252-3, DPak (2 Leads + Tab), SC-63
AOD4189 Overview
A device's maximal input capacitance is 1870pF @ 20V, which is defined as the capacitance between its input terminals with either input grounded.This device's continuous drain current (ID) is -40A, which represents the maximum continuous current it can conduct.In this device, the drain-source breakdown voltage is -40V and the drain-source breakdown voltage is the VDS at which a specified value of ID flows.Its turn-off delay time is 38 ns, which is the time to charge the device's input capacitance before drain current conduction begins.In terms of pulsed drain current, it has a maximum of 50A, which is its maximum rated peak drain current.Input capacitance charging takes time before drain current conduction begins, so the turn-on delay time is 10 ns.Gate-source voltage, or VGS, is the voltage across a FET transistor's gate-source terminal, and can be 20V volts.An electrical device's threshold voltage is the point at which any of its operations will become active, and this transistor has a -1.7V threshold voltage.This transistor requires a 40V drain to source voltage (Vdss).This device reduces its overall power consumption by using drive voltage (4.5V 10V).
AOD4189 Features
a continuous drain current (ID) of -40A
a drain-to-source breakdown voltage of -40V voltage
the turn-off delay time is 38 ns
based on its rated peak drain current 50A.
a threshold voltage of -1.7V
a 40V drain to source voltage (Vdss)
AOD4189 Applications
There are a lot of Alpha & Omega Semiconductor Inc.
AOD4189 applications of single MOSFETs transistors.
- Consumer Appliances
- Lighting
- Uninterruptible Power Supply
- AC-DC Power Supply
- Synchronous Rectification for ATX 1 Server I Telecom PSU
- Motor drives and Uninterruptible Power Supplies
- Micro Solar Inverter
- DC/DC converters
- Power Tools
- Motor Drives and Uninterruptible Power Supples
